Product description
We had one goal with the Operator CR: win races. We’ve seen what 29” bikes can do on a downhill track, and the Operator CR is ready to take podiums. With two positions offering 15mm of rear wheel adjustments and 10mm of reach adjustment, it’s easier to control the feel of the bike to get the ride you want. While we spec the bike as a 29er, you are able to run 27.5” wheels as well. Shorter or longer, 29” or 27.5” you have the power to customize your ride.
GEOMETRY mminches
Size | M | L | |||
Adj Reach | 0 | +10 | 0 | +10 | |
1 | ST Length | 440 | 440 | ||
2 | TT Length | 548 | 560 | 576 | 588 |
3 | Reach | 435 | 445 | 460 | 470 |
4 | Stack | 613 | 618 | 618 | 623 |
5 | Standover | 758 | 760 | 755 | 757 |
6 | HT Angle | 62.0 | 62.0 | ||
7 | HT Length | 117 | 122 | ||
8 | ST Angle | 79.5 | 79.5 | ||
9 | CS Length | 425 [440] | 425 [440] | ||
10 | BB Drop | 20 | 22 | 20 | 22 |
11 | BB Height | 355 | 353 | 355 | 353 |
12 | Wheelbase | 1233 [1248] | 1241 [1256] | 1260 [1275] | 1269 [1284] |
13 | Front Center | 806 | 815 | 833 | 842 |
14 | Fork Length | 591 | 591 | ||
15 | Fork Offset | 56 | 56 |
