Product description
Introducing our new carbon e-bike specific MXX-e, our new bomb-proof MTB wheel was built to take on the added torque and torsional forces that an e-bike creates. MXX-e was developed from our proven Moto wheel technology. They feature a foam core 30mm internal carbon rim width to accommodate wider tire compatibility. Included are our e-bike specific patented PBO spokes, which are 33% thicker than our standard rounded spokes. Combine that with our e-bike specific "44" hub with a 35% increase in size. We upgraded to a 44mm ratchet rings and offer compatibility with Shimano Micro Spline 12-speed and Campagnolo Ekar 13-speed groupset. The "44" hub has been updated to include a slip-fit system to easily swap out end caps to accommodate, 15mm,12mm or QR axles, helping you "future-proof" your wheelset.
The MXX-e features 24 PBO spokes on Double-cross hubs that offer up free suspension with a design that deflects harsh hits in the terrain smoothing out the ride by staying true and straight throughout. This tubeless compatible wheelset will keep you on the trails for a long time. Available with thru axle compatibilty in boost and super boost options.
Spinergy’s MXX-e was developed from our proven Moto wheel technology. They feature a foam core 30mm internal carbon rim width to accommodate wider tire compatibility. Included are our e-bike specific patented PBO spokes, which are 33% thicker than our standard rounded spokes. Combine that with our e-bike specific "44" hub with a 35% increase in size, the MXX-e is meant to take on all the added torque and torsional forces applied to it. Whether you are on a trail run, cross country, or racing, the MXX-e provides the comfort and traction you need. Ride longer and harder and see the wheels take anything you can throw at them! The 26mm profile rim with PBO spokes maintain a lightweight wheelset that can be set up as tubeless.
Features 24 PBO Moto spokes on double-cross 44 e-hubs that offer up free suspension with a design that deflects harsh hits in the terrain smoothing out the ride by staying true and straight throughout. This tubeless compatible wheelset will keep you on the trails for a long time. Available with thru axle compatibilty, boost and super boost options.
Spinergy wheelsets come standard with black or white spoke colors, and are offered with optional color choices in red, green, orange, yellow, blue, purple and pink. Front is available in 12mm or 15mm thru axle option. Front is available in 110x15mm, Rear is available in 148x12mm thru axle option. Wheelset can be ordered with super boost 157x12mm rear.
Spokes | PBO 4mm |
Size | 29" and 27.5" |
Spoke Count F/R | 24 |
Lacing F/R | Double Cross |
Hub - Front | 15mm thru axle |
Optional | 110mm Boost |
Hub - Rear | 148x12mm boost thru axles |
Optional | 157x12mm super boost |
SPOKE COLORS | BLACK / BLUE / RED / YELLOW / WHITE / ORANGE / GREEN / PINK / PURPLE |
RIM STYLE / WIDTH / DEPTH | Full Carbon Fiber Clincher / 30MM-INTERNAL / 35MM-EXTERNAL / 26MM DEPTH |
Compatibility | Shimano/SRAM 11 Spd, SRAM XDR 12-Spd, Shimano Micro Spline 12 spd, Campagnolo N3W 13 spd |
DISC ROTOR MOUNT | CENTER LOCK |
Bearings | Stainless steel |
Extras | rim tape, truing tool |
Weight | Combined F/R wheelset 1,995g |
Recent articles
Spinergy
MXX-e 27.5" Wheelset
$1,699.00
