| Frame Material | Kona 6061 Aluminum Butted 134mm Travel |
| Sizes | S, M, L, XL |
| Rear Shock | RockShox Deluxe Select Trunnion |
| Fork | RockShox Recon RL Motion Control Solo Air 140mm Tapered 110mm Spacing |
| Crankarms | Shimano Deore |
| Chainrings | 30t |
| B/B | Shimano Deore PF92 |
| Pedals | n/a |
| Chain | KMC X11 |
| Freewheel | Shimano Deore 11-50t 11spd |
| Chainguide | n/a |
| F/D | n/a |
| R/D | Shimano Deore 11spd |
| Shifters | Shimano Deore 11spd |
| Brake Calipers | Alhonga 474 Hydraulic |
| Front Brake Rotor | Alhonga 180mm |
| Rear Brake Rotor | Alhonga 160mm |
| Brake Levers | Alhonga 474 Hydraulic |
| Headset | FSA No.57B |
| Handlebar | Kona XC/BC 35 |
| Stem | Kona XC/BC 35 |
| Seatpost | TranzX Dropper +RAD Internal 31.6mm |
| Seat Clamp | Kona Clamp |
| Grips | Kona Key Grip |
| Saddle | Kona Trail |
| Front Hub | Formula 110x15mm |
| Rear Hub | Formula 148x12mm |
| Spokes | Stainless Black 14g |
| Rims | WTB ST i30 TCS 2.0 |
| Front Tire | Maxxis Minion DHF EXO TR DUAL 29x2.5" WT |
| Rear Tire | Maxxis Dissector EXO TR DUAL 29x2.4" WT |
| Paint Color | Gloss Thunder w/ Sandal & Eris Decals |
| Extras | n/a |
All specifications are subject to change without notice
| Â | Size | S | M | L | XL |
| 1 | ST Length | 385 | 410 | 450 | 485 |
| 2 | TT Length | 569 | 596 | 625 | 664 |
| 3 | Reach | 425 | 450 | 475 | 510 |
| 4 | Stack | 601 | 605 | 615 | 625 |
| 5 | Standover | 715 | 725 | 725 | 725 |
| 6 | HT Angle | 66 | 66 | 66 | 66 |
| 7 | HT Length | 93 | 98 | 109 | 120 |
| 8 | ST Angle | 76.5 | 76.5 | 76.3 | 76.2 |
| 9 | CS Length | 427 | 427 | 427 | 427 |
| 10 | BB Drop | 33 | 33 | 33 | 33 |
| 11 | BB Height | 342 | 342 | 342 | 342 |
| 12 | Wheelbase | 1159 | 1186 | 1216 | 1255 |
| 13 | Front Center | 734 | 761 | 791 | 830 |
| 14 | Fork Length | 551 | 551 | 551 | 551 |
| 15 | Fork Offset | 51 | 51 | 51 | 51 |
